Wilier
Supersonica SLR Shimano Dura-Ace Di2 R9270 2x12sp
Gallery
Images
detail
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L/XL | M | XS/S |
|---|---|---|---|
| Stack | 520mm | 500mm | 480mm |
| Reach | 439mm | 417mm | 395mm |
| Headtube length | 79mm | 79mm | 58mm |
| Headtube angle | 72deg | 72deg | 72deg |
| BB height | — | — | — |
| BB drop | — | — | — |
| Trail | — | — | — |
| Fork length | — | — | — |
| Fork offset | — | — | — |
| Front center | — | — | — |
| Chainstay length | 405mm | 405mm | 405mm |
| Wheelbase | 1030mm | 1001mm | 973mm |
| Top tube | — | — | — |
| Standover height | 756mm | 711mm | 667mm |
| Seat tube length | 525mm | 505mm | 485mm |
| Seat tube angle | 82deg | 82deg | 82deg |
Spec geometry
| Geometry | L/XL | M | XS/S |
|---|---|---|---|
| Crank length | — | — | — |
| Stem length | — | — | — |
| Handlebar width | 380mm | 380mm | 380mm |
| Handlebar reach | — | — | — |
| Handlebar drop | — | — | — |
| Saddle width | 137mm | 137mm | 137mm |
| Dropper post travel | — | — | — |
| Seatpost offset | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Supersonica SLR - Carbon monocoque
Suspension
Fork
Supersonica SLR - Carbon monocoque
Brakes
Front brake
Shimano Dura-Ace BR-R9270 hydraulic disc
Rear brake
Shimano Dura-Ace BR-R9270 hydraulic disc
Front rotor
Shimano Dura-Ace RT-RT900 SS 140mm
Rear rotor
Shimano Dura-Ace RT-RT900 SS 140mm
Drivetrain
Shift levers
Shimano Dura-Ace Di2 ST-R9180
Rear derailleur
Shimano Dura-Ace Di2 RD-R9250
Front derailleur
Shimano Dura-Ace Di2 FD-R9250
Cassette
Shimano Dura-Ace CS-R9200-12 12-speed 11-30T
Chain
Shimano Dura-Ace CN-M9100
Crankset
Shimano Dura-Ace FC-R9200 54-40T
Bottom bracket
Miche Integrale RD / CeramicSpeed PressFit 86.5x41
Cockpit
Stem
Integrated (not specified)
Handlebars
Supersonica Bar 38mm + Profile Design 43 ASC Pro extensions
Saddle
Prologo Nago R4 PAS Carbon rails 137mm
Seatpost
Integrated seatpost (cut-to-fit)
Wheels & Tires
Front wheel
Miche Kleos RD SPX3 (front)
Rear wheel
Miche Kleos RD Crono Lenticular (rear)
Front tire
Vittoria Corsa Graphene 2.0 Nero 700x25 TLR
Rear tire
Vittoria Corsa Graphene 2.0 Nero 700x25 TLR
Weight
Weight
9.4 kg +/- 5%
