Trek
Slash 9.9 X0 AXS T-Type Gen 6
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | ML | S | XL |
|---|---|---|---|---|---|
| Stack | 64.1mm | 62.3mm | 63.2mm | 58.8mm | 65.9mm |
| Reach | 48.8mm | 44.8mm | 46.8mm | 43mm | 51.3mm |
| Headtube length | 12mm | 10mm | 11mm | 10mm | 14mm |
| Headtube angle | 63.3deg | 63.3deg | 63.3deg | 63.5deg | 63.3deg |
| BB height | 35.1mm | 35.1mm | 35.1mm | 35.2mm | 35.1mm |
| BB drop | 2.7mm | 2.7mm | 2.7mm | 1mm | 2.7mm |
| Trail | 14.3mm | 14.3mm | 14.3mm | 13.2mm | 14.3mm |
| Fork length | — | — | — | — | — |
| Fork offset | 4.3mm | 4.3mm | 4.3mm | 4.3mm | 4.3mm |
| Front center | — | — | — | — | — |
| Chainstay length | 43.4mm | 42.9mm | 43.4mm | 42.9mm | 43.9mm |
| Wheelbase | 127.8mm | 122.4mm | 125.3mm | 119.5mm | 131.2mm |
| Top tube | 62.8mm | 57.8mm | 60.5mm | 54.8mm | 65.8mm |
| Standover height | 76.7mm | 76.6mm | 76.6mm | 72.7mm | 76.8mm |
| Seat tube length | 43.5mm | 40mm | 42mm | 39mm | 47mm |
| Seat tube angle | 73.8deg | 73.8deg | 73.8deg | 74deg | 73.8deg |
Spec geometry
| Geometry | L | M | ML | S | XL |
|---|---|---|---|---|---|
| Crank length | 165mm | 165mm | 165mm | 165mm | 165mm |
| Stem length | 35mm | 35mm | 35mm | 35mm | 35mm |
| Handlebar width | 820mm | 820mm | 820mm | 820mm | 820mm |
| Handlebar reach | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — |
| Saddle width | 145mm | 145mm | 145mm | 145mm | 145mm |
| Dropper post travel | 200mm | 175mm | 175mm | 150mm | 200mm |
| Seatpost offset | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
OCLV Mountain Carbon, high main pivot, idler pulley, internal storage, angle-adjust headset, adjustable leverage rate, integrated frame protection, internal routing, alloy rocker link, ISCG 05, Active Braking Pivot, UDH, 148x12mm thru axle, 170mm travel
Suspension
Rear shock
RockShox Vivid Ultimate, 230mm x 65mm
Fork
RockShox ZEB Ultimate, DebonAir spring, Charger 3.1 RC2 damper, tapered steerer, 44mm offset, Boost110, Maxle Stealth, 170mm travel
Brakes
Front brake
SRAM Maven Silver 4-piston hydraulic disc
Rear brake
SRAM Maven Silver 4-piston hydraulic disc
Front rotor
SRAM HS2, 6-bolt, 200mm
Rear rotor
SRAM HS2, 6-bolt, 200mm
Drivetrain
Shift levers
SRAM AXS Pod
Rear derailleur
SRAM X0 Eagle AXS, T-Type
Cassette
SRAM Eagle XS-1295, T-Type, 10-52, 12-speed
Chain
SRAM X0 Eagle, T-Type, 12-speed
Crankset
SRAM X0 Eagle, T-Type, DUB, 30T ring, 55mm chainline, 165mm length
Bottom bracket
SRAM DUB MTB Wide, 73mm, BSA threaded
Cockpit
Stem
Bontrager Line Pro, 35mm, Blendr compatible, 0 degree, 35mm length
Handlebars
Bontrager Line Pro, OCLV Carbon, 35mm clamp, 27.5mm rise, 820mm width
Grips
Trek Line Pro, lock-on
Saddle
Verse Short Elite, hollow magnesium rails, 145mm width
Seatpost
RockShox Reverb AXS (wireless, 34.9mm): Size S 150mm travel (442mm length); Size M/ML 175mm travel (492mm length); Size L/XL 200mm travel (542mm length)
Wheels & Tires
Front wheel
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle (Size S: 27.5in; Sizes M/ML/L/XL: 29in)
Rear wheel
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle, 27.5in
Front tire
Bontrager (TR) RSL SE, Tubeless Ready, triple compound, 60tpi (Size S: Brevard 27.5x2.5; Sizes M/ML/L/XL: Galbraith 29x2.5)
Rear tire
Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60tpi, 27.5x2.5
Weight
Weight
Size M: 16.53 kg / 36.45 lb (with TLR sealant, no tubes)
