Santa Cruz
Nomad 70
Gallery
Images
detail
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | l | m | s | xl | xxl |
|---|---|---|---|---|---|
| Stack | 638mm | 625mm | 616mm | 656mm | 670mm |
| Reach | 475mm | 455mm | 430mm | 495mm | 520mm |
| Headtube length | 115mm | 100mm | 90mm | 135mm | 150mm |
| Headtube angle | 63.8deg | 63.8deg | 63.8deg | 63.8deg | 63.8deg |
| BB height | 346mm | 346mm | 346mm | 346mm | 346mm |
| BB drop | — | — | — | — | — |
| Trail | — | — | — | — | — |
| Fork length | — | — | — | — | — |
| Fork offset | — | — | — | — | — |
| Front center | 826mm | 799mm | 770mm | 855mm | 886mm |
| Chainstay length | 443mm | 440mm | 439mm | 446mm | 450mm |
| Wheelbase | 1269mm | 1239mm | 1209mm | 1301mm | 1336mm |
| Top tube | 612mm | 594mm | 570mm | 637mm | 666mm |
| Standover height | 723mm | 716mm | 709mm | 722mm | 725mm |
| Seat tube length | 430mm | 405mm | 380mm | 460mm | 500mm |
| Seat tube angle | 77.9deg | 77.4deg | 77.2deg | 77.8deg | 77.7deg |
Spec geometry
| Geometry | l | m | s | xl | xxl |
|---|---|---|---|---|---|
| Crank length | — | — | — | — | — |
| Stem length | 42mm | 42mm | 42mm | 42mm | 42mm |
| Handlebar width | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — |
| Saddle width | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Carbon C MX, 170mm travel VPP
Suspension
Rear shock
FOX Float X Performance, 230x65 (65mm stroke)
Fork
RockShox ZEB Base, 170mm, 44mm offset
Brakes
Front brake
SRAM DB8
Rear brake
SRAM DB8
Front rotor
SRAM Centerline, 200mm
Rear rotor
SRAM Centerline, 200mm
Drivetrain
Shift levers
SRAM 90 Eagle T-Type (right shifter)
Rear derailleur
SRAM 70 Eagle T-Type, 12-speed
Cassette
SRAM XS-1270 Eagle T-Type, 12-speed, 10-52T
Chain
SRAM 70 Eagle T-Type Flattop, 12-speed
Crankset
SRAM 70 Eagle DUB T-Type crankset, 32T
Bottom bracket
SRAM DUB 73mm MTB Wide BB (73mm threaded shell)
Cockpit
Stem
OneUp Enduro Stem, 42mm
Handlebars
Burgtec Alloy Bar
Grips
Santa Cruz Bicycles House Grips
Saddle
SDG Bel-Air V3, Steel
Seatpost
SDG Tellis Dropper, 31.6
Wheels & Tires
Front wheel
Reserve 30|TR AL; SRAM MTH 716, 15x110, 6-bolt, 32h
Rear wheel
Reserve 30|HD AL; SRAM MTH 746, 12x148, HG, 6-bolt, 32h
Front tire
Maxxis Assegai 29x2.5, 3C MaxxGrip, EXO+
Rear tire
Maxxis Minion DHR II 27.5x2.4, 3C MaxxTerra, DoubleDown
Weight
Weight
35.92 lb / 16.29 kg
