Santa Cruz
Chameleon D
Gallery
Images
action
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | l | m | s | xl |
|---|---|---|---|---|
| Stack | 638.2mm | 629.2mm | 620.1mm | 647.3mm |
| Reach | 465mm | 445mm | 420mm | 490mm |
| Headtube length | 120mm | 110mm | 100mm | 130mm |
| Headtube angle | 65deg | 65deg | 65deg | 65deg |
| BB height | 315mm | 315mm | 315mm | 315mm |
| BB drop | 56mm | 56mm | 56mm | 56mm |
| Trail | — | — | — | — |
| Fork length | — | — | — | — |
| Fork offset | — | — | — | — |
| Front center | 782.8mm | 758.6mm | 729.4mm | 812.1mm |
| Chainstay length | 425mm | 425mm | 425mm | 425mm |
| Wheelbase | 1207.8mm | 1183.6mm | 1154.4mm | 1237.1mm |
| Top tube | 643.4mm | 621.3mm | 596.1mm | 668.8mm |
| Standover height | 686mm | 682mm | 682mm | 708mm |
| Seat tube length | 430mm | 405mm | 380mm | 460mm |
| Seat tube angle | 74.4deg | 74.3deg | 74.1deg | 74.6deg |
Spec geometry
| Geometry | l | m | s | xl |
|---|---|---|---|---|
| Crank length | — | — | — | — |
| Stem length | — | — | — | — |
| Handlebar width | — | — | — | — |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | — | — | — | — |
| Dropper post travel | — | — | — | — |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Santa Cruz Chameleon D, Aluminum
Suspension
Fork
RockShox Recon Silver RL, 130mm, 42mm offset
Brakes
Front brake
SRAM Level hydraulic disc
Rear brake
SRAM Level hydraulic disc
Front rotor
Avid Centerline, 180mm
Rear rotor
Avid Centerline, 180mm
Drivetrain
Shift levers
SRAM NX Eagle, 12-speed (right shifter)
Rear derailleur
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1230, 12-speed, 11-50T
Chain
SRAM SX Eagle, 12-speed
Crankset
SRAM X1 Eagle 148 DUB, 32T (max 34T)
Bottom bracket
SRAM DUB 68/73mm threaded BB (73mm threaded shell)
Cockpit
Stem
RaceFace Chester
Handlebars
RaceFace Ride
Grips
Santa Cruz Bicycles House Grips
Saddle
WTB Silverado Medium, Steel -or- WTB Volt
Seatpost
SDG Tellis Dropper, 31.6mm
Wheels & Tires
Front wheel
WTB ST i30 TCS 2.0, 29"; SRAM MTH 716, 15x110, Torque Cap, 6-bolt, 32h
Rear wheel
WTB ST i30 TCS 2.0, 29"; SRAM MTH 746, 12x148, HG, 6-bolt, 32h
Front tire
Maxxis Minion DHF 29x2.5 WT, 3C MaxxGrip, EXO
Rear tire
Maxxis Aggressor 29x2.5 WT, EXO
Weight
Weight
31 lbs / 14.06 kg
