Santa Cruz
Blur 90 Trail
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 607mm | 597mm | 587mm | 621mm |
| Reach | 458mm | 438mm | 412mm | 483mm |
| Headtube length | 110mm | 100mm | 90mm | 125mm |
| Headtube angle | 67.1deg | 67.1deg | 67.1deg | 67.1deg |
| BB height | 340mm | 340mm | 340mm | 339mm |
| BB drop | 33mm | 33mm | 33mm | 33mm |
| Trail | — | — | — | — |
| Fork length | — | — | — | — |
| Fork offset | — | — | — | — |
| Front center | 747mm | 724mm | 695mm | 778mm |
| Chainstay length | 436mm | 433mm | 431mm | 438mm |
| Wheelbase | 1183mm | 1157mm | 1126mm | 1216mm |
| Top tube | 621mm | 597mm | 568mm | 652mm |
| Standover height | 745mm | 746mm | 744mm | 750mm |
| Seat tube length | 470mm | 430mm | 405mm | 520mm |
| Seat tube angle | 74.9deg | 75deg | 75.1deg | 74.8deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | — | — | — | — |
| Stem length | 60mm | 60mm | 60mm | 60mm |
| Handlebar width | 760mm | 760mm | 760mm | 760mm |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | — | — | — | — |
| Dropper post travel | — | — | — | — |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Carbon C 29" 115mm Travel Superlight™
Suspension
Rear shock
FOX Float SL Performance, 190x45
Fork
FOX 34 SL Float Performance, GRIP, 120mm
Brakes
Front brake
SRAM DB8
Rear brake
SRAM DB8
Front rotor
SRAM HS2 180mm
Rear rotor
SRAM HS2 180mm
Drivetrain
Shift levers
SRAM 90 Eagle T-Type, 12spd
Rear derailleur
SRAM 90 Eagle T-Type, 12spd
Cassette
SRAM XS 1275 Eagle T-Type, 10-52t
Chain
SRAM GX Eagle T-Type, Flattop, 12spd
Crankset
SRAM 90 Eagle DUB T-Type Crankset, 34t
Bottom bracket
SRAM DUB 73mm MTB Wide BB
Cockpit
Stem
SRAM Atmos Stem, 60mm
Handlebars
SRAM Atmos Flat Bar, 31.8x760
Grips
ESI Chunky Grips
Saddle
SDG Bel-Air V3 Lux-Alloy
Seatpost
OneUp Dropper Post, 31.6
Wheels & Tires
Front wheel
RaceFace AR Offset 27 29"; DT Swiss 370, 15x110, 6-Bolt, 28h
Rear wheel
RaceFace AR Offset 27 29"; DT Swiss 370, 12x148, XD, 6-Bolt, 36t, 28h
Front tire
Maxxis Rekon 29"x2.4"WT, 3C MaxxTerra, EXO
Rear tire
Maxxis Rekon 29"x2.4"WT, 3C MaxxTerra, EXO
Weight
Weight
28.1 lbs / 12.75 kg
