Salsa
Rustler C SLX
Gallery
Images
detail
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | Large | Medium | Small | X-Large | X-Small |
|---|---|---|---|---|---|
| Stack | 611mm | 602mm | 593mm | 621mm | 584mm |
| Reach | 458mm | 439mm | 420mm | 476mm | 391mm |
| Headtube length | 130mm | 120mm | 110mm | 140mm | 100mm |
| Headtube angle | 65.8deg | 65.8deg | 65.8deg | 65.8deg | 65.8deg |
| BB height | — | — | — | — | — |
| BB drop | 12mm | 12mm | 12mm | 12mm | 12mm |
| Trail | — | — | — | — | — |
| Fork length | 542mm | 542mm | 542mm | 542mm | 542mm |
| Fork offset | 37mm | 37mm | 37mm | 37mm | 37mm |
| Front center | — | — | — | — | — |
| Chainstay length | 426mm | 426mm | 426mm | 426mm | 426mm |
| Wheelbase | 1193mm | 1170mm | 1147mm | 1216mm | 1114mm |
| Top tube | 638mm | 616mm | 595mm | 659mm | 563mm |
| Standover height | 709mm | 709mm | 709mm | 709mm | 706mm |
| Seat tube length | 470mm | 432mm | 406mm | 508mm | 368mm |
| Seat tube angle | 73.7deg | 73.7deg | 73.7deg | 73.7deg | 73.7deg |
Spec geometry
| Geometry | Large | Medium | Small | X-Large | X-Small |
|---|---|---|---|---|---|
| Crank length | 175mm | 170mm | 170mm | 175mm | 165mm |
| Stem length | 50mm | 50mm | 50mm | 50mm | 50mm |
| Handlebar width | 800mm | 800mm | 760mm | 800mm | 760mm |
| Handlebar reach | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — |
| Saddle width | 135mm | 135mm | 135mm | 135mm | 135mm |
| Dropper post travel | 170mm | 150mm | 125mm | 200mm | 125mm |
| Seatpost offset | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Rustler Carbon V1
Suspension
Rear shock
Fox Float DPS Performance
Fork
RockShox Lyrik Select+ RC, 150 mm, 37 mm offset
Brakes
Front brake
Shimano Deore M6120 four-piston hydraulic disc
Rear brake
Shimano Deore M6120 four-piston hydraulic disc
Front rotor
Shimano RT64 Center Lock, 180 mm
Rear rotor
Shimano RT64 Center Lock, 180 mm
Drivetrain
Shift levers
Shimano SLX M7100
Rear derailleur
Shimano SLX M7100 SGS
Cassette
Shimano Deore M6100, 10–51t, 12-speed
Chain
Shimano Deore M6100
Crankset
Shimano SLX M7100, 32t
Bottom bracket
Shimano SLX M7100 (spec not provided; likely threaded/BSA for this build, but unconfirmed)
Cockpit
Stem
Salsa Guide Trail, 50 mm
Handlebars
Race Face Aeffect R 35
Grips
Salsa File Tread Lock-on
Saddle
WTB Volt 250 Steel, 250 x 135 mm
Seatpost
TranzX YSI05 dropper, Shimano MT500 lever, 30 mm travel adjust (XS/SM 125 x409 mm, MD 150 x 459 mm, LG 170 x 499 mm, XL 200 x 559 mm)
Wheels & Tires
Front wheel
Shimano SLX M7110 15 x 110 mm hub, WTB ST Light i35 27.5" rim
Rear wheel
Shimano SLX M7110 12 x 148 mm hub, WTB ST Light i35 27.5" rim
Front tire
Maxxis DHF, 27.5 x 2.6, EXO, TR
Rear tire
Maxxis DHR II, 27.5 x 2.6, EXO, TR
Weight
Weight
31 lbs 5 oz (Medium)
