Ridley
Grifn RS Road Sram Red XPLR 1x13
Gallery
Images
detail
Geometry
Geometry
>
Geometry
Geometry
Spec geometry
| Geometry | (need geometry chart sizes) |
|---|---|
| Crank length | 172.5mm |
| Stem length | 110mm |
| Handlebar width | 360mm |
| Handlebar reach | — |
| Handlebar drop | — |
| Saddle width | — |
| Dropper post travel | — |
| Seatpost offset | 0mm |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Grifn RS carbon (Elite Series), TA 12x142, mudguard mounts, UDH, BB86, removable front derailleur clamp
Suspension
Fork
4ZA AllRoad RS 7E8/GRS01Bs
Brakes
Front brake
Shimano Ultegra hydraulic disc, flat-mount
Rear brake
Shimano Ultegra hydraulic disc, flat-mount
Front rotor
Shimano Ultegra Center Lock rotor
Rear rotor
Shimano Ultegra Center Lock rotor
Drivetrain
Shift levers
Shimano Ultegra Di2, 2x12-speed
Rear derailleur
Shimano Ultegra Di2, 12-speed
Front derailleur
Shimano Ultegra Di2, 2x12-speed, braze-on
Cassette
Shimano Ultegra, 12-speed, 11-30T
Chain
Shimano Ultegra 12-speed
Crankset
Shimano Ultegra, 12-speed, 52-36T, 172.5mm
Bottom bracket
BB86
Cockpit
Stem
Forza Nimbus Pro (length not specified)
Handlebars
Forza Nimbus Pro, 360mm (hoods) / 400mm (drops), stealth black
Saddle
Selle Italia SLR Boost, manganese rails, black
Seatpost
Forza Aero, zero offset, 350mm
Wheels & Tires
Front wheel
DT Swiss ERC 1400, TA 12x100mm, tubeless ready, 45mm deep, 22mm internal width
Rear wheel
DT Swiss ERC 1400, TA 12x142mm, tubeless ready, 45mm deep, 22mm internal width
Front tire
Vittoria Corsa Pro, 700x32, tubeless ready (TLR), Para-Black
Rear tire
Vittoria Corsa Pro, 700x32, tubeless ready (TLR), Para-Black
