Pinarello X X7 Shimano Ultegra Di2
Gallery
Images
action
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 425 | 450 | 470 | 495 | 510 | 525 | 540 | 560 | 590 |
|---|---|---|---|---|---|---|---|---|---|
| Stack | 527.5mm | 539.2mm | 552.4mm | 564.4mm | 575.8mm | 588.2mm | 602.4mm | 620.3mm | 640.4mm |
| Reach | 341.9mm | 352.1mm | 361.9mm | 368.5mm | 372.5mm | 376.7mm | 380.2mm | 384.1mm | 388.1mm |
| Headtube length | 123mm | 128mm | 140mm | 149mm | 159mm | 171mm | 185mm | 209mm | 230mm |
| Headtube angle | 70deg | 70.5deg | 71deg | 71.5deg | 72deg | 72.25deg | 72.5deg | 72.5deg | 72.5deg |
| BB height | — | — | — | — | — | — | — | — | — |
| BB drop | 67mm | 72mm | 72mm | 72mm | 72mm | 72mm | 72mm | 67mm | 67mm |
| Trail | — | — | — | — | — | — | — | — | — |
| Fork length | 375mm | 375mm | 375mm | 375mm | 375mm | 375mm | 375mm | 375mm | 375mm |
| Fork offset | 52mm | 52mm | 52mm | 47mm | 47mm | 47mm | 47mm | 47mm | 47mm |
| Front center | — | — | — | — | — | — | — | — | — |
| Chainstay length | 422mm | 422mm | 422mm | 422mm | 422mm | 422mm | 422mm | 422mm | 422mm |
| Wheelbase | — | — | — | — | — | — | — | — | — |
| Top tube | 492mm | 509mm | 525mm | 536mm | 545mm | 555mm | 565mm | 577mm | 590mm |
| Standover height | — | — | — | — | — | — | — | — | — |
| Seat tube length | 425mm | 450mm | 470mm | 495mm | 510mm | 525mm | 540mm | 560mm | 590mm |
| Seat tube angle | 75.25deg | 74.5deg | 74deg | 73.75deg | 73.5deg | 73.25deg | 73deg | 72.75deg | 72.5deg |
Spec geometry
| Geometry | 425 | 450 | 470 | 495 | 510 | 525 | 540 | 560 | 590 |
|---|---|---|---|---|---|---|---|---|---|
| Crank length | — | — | — | — | — | — | — | — | — |
| Stem length | — | — | — | — | — | — | — | — | — |
| Handlebar width | — | — | — | — | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
TorayCa T900 UD, TiCR™ cable routing, Italian BB, UCI approved
Suspension
Rear shock
null
Fork
null
Brakes
Front brake
Shimano Ultegra R8150 hydraulic disc, 2-piston caliper
Rear brake
Shimano Ultegra R8150 hydraulic disc, 2-piston caliper
Front rotor
160mm
Rear rotor
140mm
Drivetrain
Shift levers
null
Rear derailleur
null
Front derailleur
Shimano Ultegra Di2 FD-R8150, 12-speed
Cassette
Shimano Ultegra 12-speed cassette (model/ratio unspecified)
Chain
Shimano Ultegra 12-speed chain (model unspecified)
Crankset
Shimano Ultegra 12-speed crankset (chainrings unspecified)
Bottom bracket
Shimano Ultegra threaded bottom bracket (Italian/ITA per frame spec)
Cockpit
Stem
MOST Talon Ultra Light (integrated)
Handlebars
MOST Talon Ultra Light (integrated)
Saddle
null
Seatpost
Pinarello Aero Seatpost
Wheels & Tires
Front wheel
MOST Ultrafast 40* (disc)
Rear wheel
MOST Ultrafast 40* (disc)
Front tire
Pirelli P7 Sport 35-622, black, 60 TPI, Nylon breaker
Rear tire
Pirelli P7 Sport 35-622, black, 60 TPI, Nylon breaker
