Pinarello
Dogma XC XX SL 100
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 605.8mm | 589.5mm | 584.9mm | 619.7mm |
| Reach | 475mm | 455mm | 426.5mm | 495mm |
| Headtube length | 105mm | 90mm | 85mm | 120mm |
| Headtube angle | 69.75deg | 69.75deg | 69.75deg | 69.75deg |
| BB height | — | — | — | — |
| BB drop | 68mm | 67.5mm | 67.5mm | 68mm |
| Trail | — | — | — | — |
| Fork length | 511mm | 511mm | 511mm | 511mm |
| Fork offset | 44mm | 44mm | 44mm | 44mm |
| Front center | 750mm | 729.2mm | 699.1mm | 775.6mm |
| Chainstay length | 427.5mm | 427.5mm | 427.5mm | 427.5mm |
| Wheelbase | — | — | — | — |
| Top tube | 634mm | 608mm | 578mm | 659.1mm |
| Standover height | — | — | — | — |
| Seat tube length | 470mm | 435mm | 405mm | 500mm |
| Seat tube angle | 75.3deg | 75.45deg | 75.5deg | 75.15deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | — | — | — | — |
| Stem length | — | — | — | — |
| Handlebar width | — | — | — | — |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | — | — | — | — |
| Dropper post travel | 100mm | 100mm | 100mm | 100mm |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Toray M40J carbon (frame material/spec as listed)
Suspension
Rear shock
Fox Float SL Factory Kashima, 190x45
Fork
Fox 32 Factory SC Kashima, 100mm
Brakes
Front brake
Shimano XTR hydraulic disc brake
Rear brake
Shimano XTR hydraulic disc brake
Front rotor
Shimano XTR 160mm
Rear rotor
Shimano XTR 160mm
Drivetrain
Shift levers
.
Rear derailleur
SRAM XX SL Eagle
Cassette
SRAM XX SL Eagle
Chain
SRAM XX SL Eagle
Crankset
SRAM XX SL Eagle (crankset/chainrings as listed)
Bottom bracket
SRAM XX SL Eagle
Cockpit
Stem
.
Handlebars
Talon Ultra XC integrated handlebar
Saddle
Lynx 2.0 XC
Seatpost
Fox Transfer SL Kashima, 30.9mm, 100mm drop
Wheels & Tires
Front wheel
DT Swiss XRC 1200 Spline wheelset (front)
Rear wheel
DT Swiss XRC 1200 Spline wheelset (rear)
Front tire
Maxxis Rekon Race, 29 x 2.25, EXO TR, 120 TPI
Rear tire
Maxxis Rekon Race, 29 x 2.25, EXO TR, 120 TPI
