Marin
San Quentin 2
Gallery
Images
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 645mm | 622.5mm | 618mm | 650mm |
| Reach | 470mm | 450mm | 422mm | 500mm |
| Headtube length | 125mm | 115mm | 110mm | 130mm |
| Headtube angle | 64deg | 64deg | 64deg | 64deg |
| BB height | 327mm | 316mm | 316mm | 327mm |
| BB drop | 50mm | 50mm | 50mm | 50mm |
| Trail | — | — | — | — |
| Fork length | — | — | — | — |
| Fork offset | 44mm | 37mm | 37mm | 44mm |
| Front center | — | — | — | — |
| Chainstay length | 430mm | 425mm | 425mm | 430mm |
| Wheelbase | 1236mm | 1203.6mm | 1173.4mm | 1268mm |
| Top tube | 619mm | 593.7mm | 564.7mm | 650mm |
| Standover height | 688mm | 656.4mm | 627.7mm | 695mm |
| Seat tube length | 410mm | 340mm | 310mm | 420mm |
| Seat tube angle | 77deg | 77deg | 77deg | 77deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | 170mm | 170mm | 170mm | 170mm |
| Stem length | 35mm | 35mm | 35mm | 35mm |
| Handlebar width | 780mm | 780mm | 780mm | 780mm |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | — | — | — | — |
| Dropper post travel | 170mm | 150mm | 120mm | 170mm |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Series 3 6061 aluminum, double-butted, internal cable routing, 12x148mm thru-axle, 73mm threaded BB
Suspension
Fork
X-Fusion Slide (29) or Sweep (27.5) Boost RC, 140mm travel, compression & rebound adjustment, 44mm offset
Brakes
Front brake
Shimano BR-MT201 hydraulic disc
Rear brake
Shimano BR-MT201 hydraulic disc
Front rotor
180mm
Rear rotor
180mm
Drivetrain
Shift levers
Shimano Deore SL-5100R, 11-speed
Rear derailleur
Shimano Deore 11-speed, SGS
Cassette
SunRace 11-speed, 11-51T, ED Black
Chain
KMC X-11 (silver/black)
Crankset
Marin forged alloy crankset, integrated steel 32T narrow-wide chainring, Boost spacing
Bottom bracket
External sealed cartridge bearing (73mm threaded)
Cockpit
Stem
Marin 3D forged alloy, 35mm
Handlebars
Marin mini-riser, 6061 double-butted aluminum, 780mm width, 28mm rise, 5° up, 9° back
Grips
Marin Grizzly lock-on
Saddle
Marin Speed Concept
Seatpost
TranzX YSP18 dropper, 30.9mm, 1x remote (S: 120mm / M: 150mm / L-XL: 170mm travel)
Wheels & Tires
Front wheel
Marin aluminum double wall, disc-specific, 29mm inner width, pinned joint, 32H, tubeless compatible; Shimano HF-MT410B, 110x15mm, 32H; 14g black stainless steel
Rear wheel
Marin aluminum double wall, disc-specific, 29mm inner width, pinned joint, 32H, tubeless compatible; Shimano HF-MT400B, 148x12mm, standard freehub body; 14g black stainless steel
Front tire
Vee Tire Co Flow Snap, 27.5x2.6, MPC compound, wire bead
Rear tire
Vee Tire Co Flow Snap, 27.5x2.6, MPC compound, wire bead
