Marin
Gestalt 2
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
No geometry data available yet.
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension
Fork
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Brakes
Front brake
Shimano BR-RX400 Hydraulic Disc
Rear brake
Shimano BR-RX400 Hydraulic Disc
Front rotor
160mm
Rear rotor
160mm
Drivetrain
Shift levers
Shimano GRX, RX400, 2x10-Speed
Rear derailleur
Shimano GRX, RX400, 10-Speed
Cassette
Shimano, HG-5010, 11-36T
Chain
KMC X10
Crankset
Shimano GRX, FC-RX600, 46/30T
Bottom bracket
Shimano
Cockpit
Stem
Marin 3D Forged Alloy
Handlebars
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Perforated Tape
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Wheels & Tires
Front wheel
Marin Aluminum Double Wall, 21mm Inner, 22mm Tall, Disc Specific, Tubeless Compatible; Forged Aluminum Alloy, Disc, 32H; 14g
Rear wheel
Marin Aluminum Double Wall, 21mm Inner, 22mm Tall, Disc Specific, Tubeless Compatible; Forged Aluminum Alloy, Disc, 32H; 14g
Front tire
Vee Tire Co., Zilent, 700x35
Rear tire
Vee Tire Co., Zilent, 700x35
