Kona
Unit Standard
$1,29936TK
Gallery
Images
geometry
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 606mm | 597mm | 588mm | 615mm |
| Reach | 475mm | 450mm | 425mm | 510mm |
| Headtube length | 130mm | 120mm | 110mm | 140mm |
| Headtube angle | 68deg | 68deg | 68deg | 68deg |
| BB height | 310mm | 310mm | 310mm | 310mm |
| BB drop | 65mm | 65mm | 65mm | 65mm |
| Trail | — | — | — | — |
| Fork length | 470mm | 470mm | 470mm | 470mm |
| Fork offset | 50mm | 50mm | 50mm | 50mm |
| Front center | 750mm | 722mm | 693mm | 789mm |
| Chainstay length | 430mm | 430mm | 430mm | 430mm |
| Wheelbase | 1173mm | 1144mm | 1115mm | 1211mm |
| Top tube | 637mm | 610mm | 582mm | 675mm |
| Standover height | 768mm | 731mm | 695mm | 810mm |
| Seat tube length | 470mm | 420mm | 370mm | 530mm |
| Seat tube angle | 75deg | 75deg | 75deg | 75deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | — | — | — | — |
| Stem length | — | — | — | — |
| Handlebar width | — | — | — | — |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | — | — | — | — |
| Dropper post travel | — | — | — | — |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Reynolds 520 butted chromoly
Suspension
Fork
Kona Plus Fork, 110mm spacing
Brakes
Front brake
Tektro HD-M275
Rear brake
Tektro HD-M275
Front rotor
Tektro 180mm
Rear rotor
Tektro 160mm
Drivetrain
Shift levers
n/a
Rear derailleur
n/a
Cassette
KT 18T
Chain
KMC Z1 Narrow
Crankset
FSA Comet Modular crankarms, 32T chainring
Bottom bracket
FSA MegaExo 73mm
Cockpit
Stem
Kona XC
Handlebars
Kona XC/BC Riser
Grips
Kona Key Grip
Saddle
WTB Volt
Seatpost
Kona Thumb w/Offset 31.6mm
Wheels & Tires
Front wheel
WTB ST i30 TCS 2.0; Formula 110x15mm; Stainless black 14g
Rear wheel
WTB ST i30 TCS 2.0; Formula 148x12mm; Stainless black 14g
Front tire
Maxxis Rekon TR 29x2.6" or WTB Ranger TCS 29x2.6"
Rear tire
Maxxis Rekon TR 29x2.6" or WTB Ranger TCS 29x2.6"
