Kona
Sutra Standard
Gallery
Images
geometry
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Stack | 551mm | 570mm | 591mm | 610mm | 632mm | 651mm |
| Reach | 375mm | 380mm | 385mm | 390mm | 395mm | 400mm |
| Headtube length | 105mm | 125mm | 150mm | 170mm | 195mm | 215mm |
| Headtube angle | 70.5deg | 70.5deg | 70.5deg | 70.5deg | 70.5deg | 70.5deg |
| BB height | 281mm | 281mm | 283mm | 283mm | 285mm | 285mm |
| BB drop | 74mm | 74mm | 72mm | 72mm | 70mm | 70mm |
| Trail | — | — | — | — | — | — |
| Fork length | 415mm | 415mm | 415mm | 415mm | 415mm | 415mm |
| Fork offset | 50mm | 50mm | 50mm | 50mm | 50mm | 50mm |
| Front center | 602mm | 613mm | 626mm | 638mm | 651mm | 662mm |
| Chainstay length | 445mm | 445mm | 445mm | 445mm | 445mm | 445mm |
| Wheelbase | 1036mm | 1047mm | 1061mm | 1073mm | 1086mm | 1098mm |
| Top tube | 523mm | 538mm | 555mm | 571mm | 588mm | 605mm |
| Standover height | 752mm | 770mm | 794mm | 817mm | 835mm | 854mm |
| Seat tube length | 480mm | 500mm | 520mm | 540mm | 560mm | 580mm |
| Seat tube angle | 75deg | 74.5deg | 74deg | 73.5deg | 73deg | 72.5deg |
Spec geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Crank length | — | — | — | — | — | — |
| Stem length | — | — | — | — | — | — |
| Handlebar width | — | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Kona Cromoly Butted
Suspension
Fork
Kona Project Two Cromoly Disc Touring
Brakes
Front brake
TRP HDC711C Mechanical / Hydraulic
Rear brake
TRP HDC711C Mechanical / Hydraulic
Front rotor
TRP TR160mm
Rear rotor
TRP TR160mm
Drivetrain
Shift levers
Microshift Sword
Rear derailleur
Microshift Sword
Front derailleur
Microshift Sword
Cassette
Microshift Sword, 10-speed, 11-38T
Chain
KMC X10
Crankset
Prowheel crankarms w/ 30/46T chainrings
Bottom bracket
Prowheel BB68+
Cockpit
Stem
Kona Road
Handlebars
Kona Road
Grips
Brooks Microfiber Brown
Saddle
Brooks B17 Leather
Seatpost
Kona Deluxe Thumb w/Offset, 27.2mm
Wheels & Tires
Front wheel
WTB ST i23 TCS 2.0; Formula, 12x100mm; Stainless Black 14g
Rear wheel
WTB ST i23 TCS 2.0; Formula, 12x142mm; Stainless Black 14g
Front tire
Schwalbe Marathon Mondial 700x40c
Rear tire
Schwalbe Marathon Mondial 700x40c
