Frame geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Stack | 551mm | 570mm | 591mm | 610mm | 632mm | 651mm |
| Reach | 375mm | 380mm | 385mm | 390mm | 395mm | 400mm |
| Headtube length | 105mm | 125mm | 150mm | 170mm | 195mm | 215mm |
| Headtube angle | 70.5deg | 70.5deg | 70.5deg | 70.5deg | 70.5deg | 70.5deg |
| BB height | 281mm | 281mm | 283mm | 283mm | 285mm | 285mm |
| BB drop | 74mm | 74mm | 72mm | 72mm | 70mm | 70mm |
| Trail | — | — | — | — | — | — |
| Fork length | 415mm | 415mm | 415mm | 415mm | 415mm | 415mm |
| Fork offset | 50mm | 50mm | 50mm | 50mm | 50mm | 50mm |
| Front center | 602mm | 613mm | 626mm | 638mm | 651mm | 662mm |
| Chainstay length | 445mm | 445mm | 445mm | 445mm | 445mm | 445mm |
| Wheelbase | 1036mm | 1047mm | 1061mm | 1073mm | 1086mm | 1098mm |
| Top tube | 523mm | 538mm | 555mm | 571mm | 588mm | 605mm |
| Standover height | 752mm | 770mm | 794mm | 817mm | 835mm | 854mm |
| Seat tube length | 480mm | 500mm | 520mm | 540mm | 560mm | 580mm |
| Seat tube angle | 75deg | 74.5deg | 74deg | 73.5deg | 73deg | 72.5deg |
Spec geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Crank length | — | — | — | — | — | — |
| Stem length | — | — | — | — | — | — |
| Handlebar width | — | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Kona Cromoly Butted
Suspension
Fork
Kona Project Two Cromoly Disc Touring Fork
Brakes
Front brake
Shimano GRX hydraulic disc brake caliper
Rear brake
Shimano GRX hydraulic disc brake caliper
Front rotor
Shimano 180mm
Rear rotor
Shimano 180mm
Drivetrain
Shift levers
Shimano GRX 1x
Rear derailleur
Shimano GRX 12-speed
Cassette
Shimano Deore 12-speed, 10-51T
Chain
Shimano Deore
Crankset
Shimano Deore crankarms, 34T Deore chainring
Bottom bracket
Shimano Deore, 73mm
Cockpit
Stem
Kona Road Deluxe
Handlebars
Kona Road
Grips
Kona Cork Tape
Saddle
WTB Volt
Seatpost
TranzX Dropper +RAD Internal, 31.6mm
Wheels & Tires
Front wheel
WTB KOM Team i27 TCS 2.0; Formula, 100x12mm; Stainless black 14g
Rear wheel
WTB KOM Team i27 TCS 2.0; Formula, 142x12mm; Stainless black 14g
Front tire
Maxxis Rekon Race EXO TR, 29x2.25"
Rear tire
Maxxis Rekon Race EXO TR, 29x2.25"
