Kona
Rove LTD (36SH)
Gallery
Images
geometry
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Stack | 532mm | 551mm | 570mm | 588mm | 607mm | 626mm |
| Reach | 372mm | 378mm | 383mm | 388mm | 392mm | 400mm |
| Headtube length | 90mm | 110mm | 130mm | 150mm | 170mm | 190mm |
| Headtube angle | 70.5deg | 70.5deg | 71deg | 71deg | 71.5deg | 71.5deg |
| BB height | 268mm | 268mm | 270mm | 270mm | 272mm | 272mm |
| BB drop | 74mm | 74mm | 72mm | 72mm | 70mm | 70mm |
| Trail | — | — | — | — | — | — |
| Fork length | 400mm | 400mm | 400mm | 400mm | 400mm | 400mm |
| Fork offset | 50mm | 50mm | 50mm | 50mm | 50mm | 50mm |
| Front center | 592mm | 604mm | 612mm | 623mm | 628mm | 643mm |
| Chainstay length | 435mm | 435mm | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1016mm | 1029mm | 1036mm | 1048mm | 1054mm | 1068mm |
| Top tube | 515mm | 531mm | 546mm | 562mm | 578mm | 598mm |
| Standover height | 735mm | 754mm | 775mm | 794mm | 815mm | 834mm |
| Seat tube length | 480mm | 500mm | 520mm | 540mm | 560mm | 580mm |
| Seat tube angle | 75deg | 74.5deg | 74deg | 73.5deg | 73deg | 72.5deg |
Spec geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Crank length | — | — | — | — | — | — |
| Stem length | — | — | — | — | — | — |
| Handlebar width | — | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Kona Butted Cromoly
Suspension
Fork
Kona Libre Full Carbon Flat Mount Disc
Brakes
Front brake
Shimano GRX hydraulic disc brake caliper
Rear brake
Shimano GRX hydraulic disc brake caliper
Front rotor
Shimano CL, 160mm
Rear rotor
Shimano CL, 160mm
Drivetrain
Shift levers
Shimano GRX
Rear derailleur
Shimano GRX, 12-speed
Front derailleur
Shimano GRX 2x
Cassette
Shimano 105, 12-speed, 11-36T
Chain
KMC X12, 12-speed
Crankset
Shimano GRX crankarms, 46/30T chainrings
Bottom bracket
Shimano Deore, 68mm
Cockpit
Stem
Kona Gravel Deluxe
Handlebars
Kona Gravel Drop Bar
Grips
Velo Shock-Proof Bar Tape
Saddle
WTB Volt
Seatpost
Kona Deluxe Thumb w/Offset, 27.2mm
Wheels & Tires
Front wheel
WTB KOM Team i23 TCS; Formula, 12x100mm; Stainless black, 14g
Rear wheel
WTB KOM Team i23 TCS; Formula, 12x142mm; Stainless black, 14g
Front tire
Maxxis Rambler EXO TR, 700x40c
Rear tire
Maxxis Rambler EXO TR, 700x40c
