Frame geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Stack | 532mm | 551mm | 570mm | 588mm | 607mm | 626mm |
| Reach | 372mm | 378mm | 383mm | 388mm | 392mm | 400mm |
| Headtube length | 90mm | 110mm | 130mm | 150mm | 170mm | 190mm |
| Headtube angle | 70.5deg | 70.5deg | 71deg | 71deg | 71.5deg | 71.5deg |
| BB height | 268mm | 268mm | 270mm | 270mm | 272mm | 272mm |
| BB drop | 74mm | 74mm | 72mm | 72mm | 70mm | 70mm |
| Trail | — | — | — | — | — | — |
| Fork length | 400mm | 400mm | 400mm | 400mm | 400mm | 400mm |
| Fork offset | 50mm | 50mm | 50mm | 50mm | 50mm | 50mm |
| Front center | 592mm | 604mm | 612mm | 623mm | 628mm | 643mm |
| Chainstay length | 435mm | 435mm | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1016mm | 1029mm | 1036mm | 1048mm | 1054mm | 1068mm |
| Top tube | 515mm | 531mm | 546mm | 562mm | 578mm | 598mm |
| Standover height | 735mm | 754mm | 775mm | 794mm | 815mm | 834mm |
| Seat tube length | 480mm | 500mm | 520mm | 540mm | 560mm | 580mm |
| Seat tube angle | 75deg | 74.5deg | 74deg | 73.5deg | 73deg | 72.5deg |
Spec geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Crank length | — | — | — | — | — | — |
| Stem length | — | — | — | — | — | — |
| Handlebar width | — | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Kona Butted Cromoly
Suspension
Fork
Kona Project Two Cromoly Disc
Brakes
Front brake
Shimano CUES hydraulic disc brake (caliper/lever)
Rear brake
Shimano CUES hydraulic disc brake (caliper/lever)
Front rotor
Shimano RT54 160mm Centerlock
Rear rotor
Shimano RT54 160mm Centerlock
Drivetrain
Shift levers
Shimano CUES
Rear derailleur
Shimano CUES, 11-speed
Cassette
Shimano CUES, 11-speed, 11-50T
Chain
Shimano CUES
Crankset
Shimano CUES crankarms, 40T chainring
Bottom bracket
Shimano BB68
Cockpit
Stem
Kona Gravel
Handlebars
Kona Gravel Dropbar
Grips
Kona Cork Tape
Saddle
WTB Volt
Seatpost
Kona Thumb w/Offset, 27.2mm
Wheels & Tires
Front wheel
WTB ST i23 TCS 2.0; Shimano 105 Road TA, 100x12mm, Centerlock; Stainless Black 14g
Rear wheel
WTB ST i23 TCS 2.0; Shimano 105 Road TA, 100x12mm, Centerlock; Stainless Black 14g
Front tire
Maxxis Rambler EXO — 650x47c (sizes 48/50/52) / 700x40c (sizes 54/56/58)
Rear tire
Maxxis Rambler EXO — 650x47c (sizes 48/50/52) / 700x40c (sizes 54/56/58)
