Kona
Libre Base
Gallery
Images
detail
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Stack | 550mm | 565mm | 580mm | 600mm | 620mm | 650mm |
| Reach | 380mm | 385mm | 390mm | 395mm | 400mm | 405mm |
| Headtube length | 109mm | 125mm | 140mm | 165mm | 186mm | 218mm |
| Headtube angle | 70.5deg | 70.5deg | 70.5deg | 70.5deg | 70.5deg | 70.5deg |
| BB height | 285mm | 285mm | 285mm | 288mm | 288mm | 288mm |
| BB drop | 75mm | 75mm | 75mm | 72mm | 72mm | 72mm |
| Trail | — | — | — | — | — | — |
| Fork length | 410mm | 410mm | 410mm | 410mm | 410mm | 410mm |
| Fork offset | 50mm | 50mm | 50mm | 50mm | 50mm | 50mm |
| Front center | 606mm | 616mm | 626mm | 639mm | 651mm | 667mm |
| Chainstay length | 435mm | 435mm | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1030mm | 1040mm | 1050mm | 1064mm | 1076mm | 1092mm |
| Top tube | 527mm | 542mm | 556mm | 573mm | 590mm | 610mm |
| Standover height | 733mm | 752mm | 770mm | 799mm | 825mm | 855mm |
| Seat tube length | 440mm | 460mm | 480mm | 510mm | 540mm | 570mm |
| Seat tube angle | 75deg | 74.5deg | 74deg | 73.5deg | 73deg | 72.5deg |
Spec geometry
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 |
|---|---|---|---|---|---|---|
| Crank length | — | — | — | — | — | — |
| Stem length | — | — | — | — | — | — |
| Handlebar width | — | — | — | — | — | — |
| Handlebar reach | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Kona 6061 Aluminum Butted
Suspension
Fork
Kona Libre Carbon Flat Mount Disc
Brakes
Front brake
Shimano Cues hydraulic disc brake caliper
Rear brake
Shimano Cues hydraulic disc brake caliper
Front rotor
Shimano RT56 180mm
Rear rotor
Shimano RT56 180mm
Drivetrain
Shift levers
Shimano Cues
Rear derailleur
Shimano Cues
Front derailleur
Shimano Cues
Cassette
Shimano Cues 10-speed 11-39T
Chain
Shimano Cues
Crankset
Shimano Cues crankarms with Shimano Cues 32/46T chainrings
Bottom bracket
Shimano BB-RS500-PB 86.5
Cockpit
Stem
Kona Gravel Deluxe
Handlebars
Kona Gravel Dropbar
Grips
Kona Cork Tape
Saddle
WTB SL8
Seatpost
Kona Thumb w/Offset 27.2mm
Wheels & Tires
Front wheel
WTB ST i23 TCS 2.0; Formula 12x100mm; Stainless Black 14g
Rear wheel
WTB ST i23 TCS 2.0; Formula 12x142mm; Stainless Black 14g
Front tire
WTB Vulpine TCS Light 700x45c
Rear tire
WTB Vulpine TCS Light 700x45c
