Kona
Hei Hei G10
Gallery
Images
geometry
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 630mm | 620mm | 606mm | 639mm |
| Reach | 474mm | 449mm | 424mm | 509mm |
| Headtube length | 130mm | 120mm | 105mm | 140mm |
| Headtube angle | 66deg | 66deg | 66deg | 66deg |
| BB height | 344mm | 344mm | 344mm | 344mm |
| BB drop | 31mm | 31mm | 31mm | 31mm |
| Trail | — | — | — | — |
| Fork length | 542mm | 542mm | 542mm | 542mm |
| Fork offset | 44mm | 44mm | 44mm | 44mm |
| Front center | 790mm | 761mm | 730mm | 829mm |
| Chainstay length | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1223mm | 1194mm | 1163mm | 1262mm |
| Top tube | 633mm | 605mm | 575mm | 671mm |
| Standover height | 753mm | 752mm | 752mm | 755mm |
| Seat tube length | 450mm | 410mm | 380mm | 490mm |
| Seat tube angle | 75.9deg | 76deg | 76.1deg | 75.8deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | — | — | — | — |
| Stem length | — | — | — | — |
| Handlebar width | — | — | — | — |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | — | — | — | — |
| Dropper post travel | — | — | — | — |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Kona Race Light 6061 Aluminum Butted, 120mm travel
Suspension
Rear shock
Fox Float Rhythm
Fork
Fox 34 Float Rhythm, 130mm, tapered steerer, 110mm spacing
Brakes
Front brake
SRAM Motive Bronze, 4-piston (caliper/lever set)
Rear brake
SRAM Motive Bronze, 4-piston (caliper/lever set)
Front rotor
SRAM Centerline, 180mm
Rear rotor
SRAM Centerline, 180mm
Drivetrain
Shift levers
SRAM Eagle 70
Rear derailleur
SRAM Eagle 70 Transmission
Cassette
SRAM 1270 Eagle T-TYPE, 10-52T, 12-speed
Chain
SRAM Eagle 70 Transmission
Crankset
SRAM Eagle DUB crankarms, 32T chainring
Bottom bracket
SRAM DUB WIDE PF92
Cockpit
Stem
Kona XC/BC 35
Handlebars
Kona XC/BC 35
Grips
Kona Key Grip
Saddle
WTB Volt
Seatpost
TranzX Dropper +RAD Internal, 31.6mm, w/ SRAM lever
Wheels & Tires
Front wheel
WTB ST i30 TCS 2.0; Formula, 110x15mm; Stainless Black
Rear wheel
WTB ST i30 TCS 2.0; Formula, 148x12mm; Stainless Black
Front tire
Maxxis Dissector, EXO TR, 29x2.4"
Rear tire
Maxxis Dissector, EXO TR, 29x2.4"
