Kona
Cinder Cone Standard
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 608mm | 599mm | 585mm | 622mm |
| Reach | 465mm | 440mm | 415mm | 500mm |
| Headtube length | 125mm | 115mm | 100mm | 140mm |
| Headtube angle | 68deg | 68deg | 68deg | 68deg |
| BB height | 305mm | 305mm | 305mm | 305mm |
| BB drop | 50mm | 50mm | 50mm | 50mm |
| Trail | — | — | — | — |
| Fork length | 490mm | 490mm | 490mm | 490mm |
| Fork offset | 42mm | 42mm | 42mm | 42mm |
| Front center | 737mm | 709mm | 678mm | 778mm |
| Chainstay length | 435mm | 435mm | 435mm | 435mm |
| Wheelbase | 1168mm | 1139mm | 1109mm | 1208mm |
| Top tube | 628mm | 600mm | 572mm | 667mm |
| Standover height | 725mm | 719mm | 710mm | 748mm |
| Seat tube length | 470mm | 420mm | 370mm | 530mm |
| Seat tube angle | 75deg | 75deg | 75deg | 75deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | — | — | — | — |
| Stem length | — | — | — | — |
| Handlebar width | — | — | — | — |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | — | — | — | — |
| Dropper post travel | — | — | — | — |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Kona Race Light 6061 Aluminum Butted
Suspension
Fork
RockShox Judy Silver TK Solo Air, 100mm
Brakes
Front brake
Alhonga HT472 hydraulic disc
Rear brake
Alhonga HT472 hydraulic disc
Front rotor
Alhonga 180mm (Center Lock)
Rear rotor
Alhonga 160mm (Center Lock)
Drivetrain
Shift levers
Shimano Deore
Rear derailleur
Shimano Deore
Cassette
Shimano Deore, 11-speed, 11-51T
Chain
KMC X11
Crankset
Prowheel 11-speed crankarms, 28T chainring
Bottom bracket
FSA BB7420, 73mm
Cockpit
Stem
Kona XC
Handlebars
Kona XC/BC Riser
Grips
Kona Key Grip Slip On
Saddle
Kona XC
Seatpost
Kona Thumb, 31.6mm
Wheels & Tires
Front wheel
WTB ST i27 TCS 2.0; Formula 100x9mm (Center Lock); Stainless Black 14g
Rear wheel
WTB ST i27 TCS 2.0; Shimano 135x10mm (Center Lock); Stainless Black 14g
Front tire
Maxxis Forekaster 27.5x2.35"
Rear tire
Maxxis Forekaster 27.5x2.35"
