Cervelo
Aspero GRX RX820
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 48 | 51 | 54 | 56 | 58 | 61 | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack | 505mm | 530mm | 555mm | 580mm | 605mm | 630mm | — | — | — | — | — | — |
| Reach | 370mm | 379mm | 388mm | 397mm | 406mm | 415mm | — | — | — | — | — | — |
| Headtube length | 83mm | 107mm | 133mm | 159mm | 188mm | 214mm | — | — | — | — | — | — |
| Headtube angle | 71deg | 71.5deg | 72deg | 72deg | 72deg | 72deg | — | — | — | — | — | — |
| BB height | — | — | — | — | — | — | — | — | — | — | — | — |
| BB drop | 78.5mm | 78.5mm | 76mm | 76mm | 73.5mm | 73.5mm | — | — | — | — | — | — |
| Trail | 62mm | 62mm | 62mm | 62mm | 62mm | 62mm | — | — | — | — | — | — |
| Fork length | — | — | — | — | — | — | — | — | — | — | — | — |
| Fork offset | — | — | — | — | — | — | — | — | — | — | — | — |
| Front center | — | — | — | — | — | — | — | — | — | — | — | — |
| Chainstay length | 425mm | 425mm | 425mm | 425mm | 425mm | 425mm | — | — | — | — | — | — |
| Wheelbase | — | — | — | — | — | — | — | — | — | — | — | — |
| Top tube | 512mm | 532mm | 553mm | 575mm | 591mm | 608mm | — | — | — | — | — | — |
| Standover height | 681mm | 704mm | 733mm | 757mm | 784mm | 808mm | — | — | — | — | — | — |
| Seat tube length | — | — | — | — | — | — | — | — | — | — | — | — |
| Seat tube angle | 74.5deg | 74deg | 73.5deg | 73deg | 73deg | 73deg | — | — | — | — | — | — |
Spec geometry
| Geometry | 48 | 51 | 54 | 56 | 58 | 61 | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Crank length | — | — | — | — | — | — | 170mm | 170mm | 170mm | 170mm | 172.5mm | 172.5mm |
| Stem length | — | — | — | — | — | — | 80mm | 80mm | 90mm | 90mm | 100mm | 100mm |
| Handlebar width | — | — | — | — | — | — | 360mm | 380mm | 400mm | 400mm | 420mm | 420mm |
| Handlebar reach | — | — | — | — | — | — | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — | 0mm | 0mm | 0mm | 0mm | 0mm | 15mm |
Specs
Full specs
>
Specs
Full specs
Suspension
Fork
Cervélo All-Carbon, Tapered Aspero Fork
Brakes
Front rotor
Shimano CL800 Centerlock
Rear rotor
Shimano CL800 Centerlock
Drivetrain
Shift levers
Shimano GRX, RX820
Rear derailleur
Shimano GRX, RX820
Front derailleur
Shimano GRX, RX820
Cassette
Shimano HG710, 11-36T, 12-Speed
Chain
Shimano M8100
Crankset
Shimano GRX, RX820, 48/31T
Bottom bracket
FSA, T47 BBright for 24mm spindle
Cockpit
Stem
Cervélo ST36 Alloy
Handlebars
Cervélo AB09 Carbon, 31.8mm clamp, 16 degree flare
Saddle
Prologo Nago R4 PAS Steel
Seatpost
Cervélo SP19 Carbon 27.2
Wheels & Tires
Front wheel
Reserve 30 GR AL, Reserve 4LD, 12x100mm, 24H, centerlock, tubeless compatible
Rear wheel
Reserve 30 GR AL, Reserve 4LD, 12x142mm, XDR freehub, 24H, centerlock, tubeless compatible
Front tire
WTB Vulpine TCS Light Fast Rolling Dual DNA 60tpi 700x45c
Rear tire
WTB Vulpine TCS Light Fast Rolling Dual DNA 60tpi 700x45c
