Cannondale
Synapse Carbon 2 SmartSense
Gallery
Images
action
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 44.0 | 48.0 | 51.0 | 54.0 | 56.0 | 58.0 | 61.0 |
|---|---|---|---|---|---|---|---|
| Stack | 510mm | 530mm | 550mm | 570mm | 590mm | 610mm | 640mm |
| Reach | 366mm | 371mm | 376mm | 381mm | 387mm | 393mm | 402mm |
| Headtube length | 91mm | 108mm | 127mm | 150mm | 171mm | 196mm | 227mm |
| Headtube angle | 69.8deg | 70.9deg | 71.3deg | 71.3deg | 71.3deg | 71.3deg | 71.3deg |
| BB height | 278mm | 278mm | 278mm | 280mm | 280mm | 283mm | 283mm |
| BB drop | 75mm | 75mm | 75mm | 73mm | 73mm | 70mm | 70mm |
| Trail | 71mm | 64mm | 61mm | 61mm | 61mm | 61mm | 61mm |
| Fork length | 393mm | 393mm | 393mm | 393mm | 393mm | 393mm | 393mm |
| Fork offset | 55mm | 55mm | 55mm | 55mm | 55mm | 55mm | 55mm |
| Front center | 589mm | 592mm | 600mm | 612mm | 624mm | 638mm | 657mm |
| Chainstay length | 425mm | 425mm | 425mm | 425mm | 430mm | 430mm | 430mm |
| Wheelbase | 1003mm | 1005mm | 1013mm | 1026mm | 1044mm | 1058mm | 1077mm |
| Top tube | 522mm | 533mm | 544mm | 555mm | 567mm | 580mm | 598mm |
| Standover height | 714mm | 722mm | 752mm | 785mm | 815mm | 843mm | 878mm |
| Seat tube length | 407mm | 407mm | 443mm | 480mm | 520mm | 550mm | 590mm |
| Seat tube angle | 73deg | 73deg | 73deg | 73deg | 73deg | 73deg | 73deg |
Spec geometry
| Geometry | 44.0 | 48.0 | 51.0 | 54.0 | 56.0 | 58.0 | 61.0 |
|---|---|---|---|---|---|---|---|
| Crank length | 165mm | 170mm | 170mm | 172.5mm | 172.5mm | 175mm | 175mm |
| Stem length | 80mm | 80mm | 90mm | 100mm | 100mm | 110mm | 110mm |
| Handlebar width | 400mm | 400mm | 400mm | 420mm | 420mm | 420mm | 420mm |
| Handlebar reach | — | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — | — |
| Saddle width | 140mm | 140mm | 140mm | 140mm | 140mm | 140mm | 140mm |
| Dropper post travel | — | — | — | — | — | — | — |
| Seatpost offset | 0mm | 0mm | 15mm | 15mm | 15mm | 15mm | 15mm |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Synapse Carbon, Proportional Response construction, integrated cable routing, downtube Stashport, 12x142mm thru-axle, UDH, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense Gen 2.0 equipped, fender mounts
Suspension
Fork
Synapse Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/5" Delta steerer, 55mm offset, fender mounts
Brakes
Front brake
SRAM Force AXS hydraulic disc
Rear brake
SRAM Force AXS hydraulic disc
Front rotor
160mm SRAM Centerline XR, Centerlock
Rear rotor
160mm SRAM Centerline XR, Centerlock
Drivetrain
Shift levers
SRAM Force AXS
Rear derailleur
SRAM Force AXS
Front derailleur
SRAM Force AXS, braze-on
Cassette
SRAM Force XG-1270, 10-36T, 12-speed
Chain
SRAM Force
Crankset
SRAM Force, 46/33: 165mm (44cm), 170mm (48-51cm), 172.5mm (54-56cm), 175mm (58-61cm)
Bottom bracket
SRAM DUB BSA (BSA 68mm threaded)
Cockpit
Stem
Cannondale C1 Conceal, Alloy, 31.8, -6°: 80mm (44-48cm), 90mm (51cm), 100mm (54-56cm), 110mm (58-61cm)
Handlebars
Vision Trimax Aero Alloy: 400mm (44-51cm), 420mm (54-61cm)
Grips
Cannondale Bar Tape, 3.5mm
Saddle
Fizik Vento Argo R5, 140mm
Seatpost
Cannondale C1 Aero 27 Carbon, SmartSense compatible, 330mm length, 0mm offset (44-48cm), 15mm offset (51-61cm)
Wheels & Tires
Front wheel
Reserve 42 | 49 Turbulent Aero, 24h, tubeless ready; DT Swiss 370, 12x100mm, Centerlock; Sapim CX-Delta J-bend
Rear wheel
Reserve 42 | 49 Turbulent Aero, 24h, tubeless ready; DT Swiss 370 LN Ratchet System, 12x142mm, Centerlock; Sapim CX-Delta J-bend
Front tire
Vittoria Rubino Pro IV, 700x32c
Rear tire
Vittoria Rubino Pro IV, 700x32c
