Cannondale
Habit 26
Gallery
Images
other
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | LG | MD | SM | XL | XS |
|---|---|---|---|---|---|
| Stack | 641mm | 632mm | 623mm | 650mm | 575mm |
| Reach | 480mm | 455mm | 430mm | 515mm | 405mm |
| Headtube length | 130mm | 120mm | 110mm | 140mm | 100mm |
| Headtube angle | 65.5deg | 65.5deg | 65.5deg | 65.5deg | 65.5deg |
| BB height | 341mm | 341mm | 341mm | 341mm | 342mm |
| BB drop | 38mm | 38mm | 38mm | 38mm | 16mm |
| Trail | 127mm | 127mm | 127mm | 127mm | 122mm |
| Fork length | — | — | — | — | — |
| Fork offset | 42mm | 42mm | 42mm | 42mm | 37mm |
| Front center | 796mm | 767mm | 738mm | 835mm | 696mm |
| Chainstay length | 440mm | 435mm | 434mm | 445mm | 434mm |
| Wheelbase | 1234mm | 1200mm | 1170mm | 1278mm | 1129mm |
| Top tube | 617mm | 590mm | 563mm | 654mm | 527mm |
| Standover height | 751mm | 735mm | 730mm | 762mm | 705mm |
| Seat tube length | 445mm | 400mm | 380mm | 500mm | 360mm |
| Seat tube angle | 72deg | 71deg | 70.5deg | 73deg | 71.5deg |
Spec geometry
| Geometry | LG | MD | SM | XL | XS |
|---|---|---|---|---|---|
| Crank length | — | — | — | — | — |
| Stem length | — | — | — | — | — |
| Handlebar width | 720mm | 720mm | 720mm | 720mm | 720mm |
| Handlebar reach | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — |
| Saddle width | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
SmartForm C3 Alloy, 120mm travel, 1-1/8" to 1-1/2" tapered headtube, IS disc mount, StraightShot internal cable routing, dropper post compatible, BSA-73, 142x12mm thru-axle, UDH derailleur hanger
Suspension
Rear shock
X-Fusion O2 Pro w/ Rebound Adjust
Fork
SR Suntour XCR34, 120mm travel, air spring, 15x110 Boost thru-axle, 46mm offset
Brakes
Front brake
Tektro M275 hydraulic disc
Rear brake
Tektro M275 hydraulic disc
Front rotor
160mm
Rear rotor
160mm
Drivetrain
Shift levers
microSHIFT Advent X, trigger style, 10-speed
Rear derailleur
microSHIFT Advent X
Cassette
microSHIFT, 11-48T, 10-speed
Chain
KMC X10, 10-speed
Crankset
Prowheel Charm 30T
Bottom bracket
Sealed cartridge bearing, square taper
Cockpit
Stem
6061 Alloy, 31.8mm clamp, 7°
Handlebars
Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
Grips
Cannondale Dual-Density
Saddle
Cannondale Stage 3
Seatpost
Cannondale 3, 6061 Alloy, 31.6x350mm
Wheels & Tires
Front wheel
WTB STX i25, 32h; Formula, 15x110mm thru-axle; Stainless steel, 14g
Rear wheel
WTB STX i25, 32h; Formula, 12x148mm thru-axle; Stainless steel, 14g
Front tire
WTB Vigilante, 26x2.4"
Rear tire
WTB Vigilante, 26x2.4"
