Bianchi
Specialissima RC Pantani Super Record WRL 13sp
Gallery
Images
lifestyle
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | 470 | 500 | 530 | 550 | 570 | 590 |
|---|---|---|---|---|---|---|
| Stack | 486mm | 494mm | 520mm | 536mm | 552mm | 571mm |
| Reach | 379mm | 387mm | 386mm | 391mm | 397mm | 400mm |
| Headtube length | 100mm | 105mm | 120mm | 135mm | 150mm | 170mm |
| Headtube angle | 70.5deg | 71.5deg | 72deg | 72.5deg | 73deg | 73deg |
| BB height | — | — | — | — | — | — |
| BB drop | — | — | — | — | — | — |
| Trail | 58mm | 58mm | 68mm | 68mm | 68mm | 68mm |
| Fork length | 368mm | 368mm | 368mm | 368mm | 368mm | 368mm |
| Fork offset | 43mm | 43mm | 43mm | 43mm | 43mm | 43mm |
| Front center | 579mm | 581mm | 582mm | 588mm | 593mm | 603mm |
| Chainstay length | 410mm | 410mm | 410mm | 410mm | 412mm | 412mm |
| Wheelbase | 982mm | 983mm | 984mm | 988mm | 996mm | 1005mm |
| Top tube | 514mm | 524mm | 535mm | 550mm | 560mm | 575mm |
| Standover height | — | — | — | — | — | — |
| Seat tube length | 420mm | 450mm | 480mm | 500mm | 520mm | 540mm |
| Seat tube angle | 74.5deg | 74.5deg | 74deg | 73.5deg | 73.5deg | 73deg |
Spec geometry
| Geometry | 470 | 500 | 530 | 550 | 570 | 590 |
|---|---|---|---|---|---|---|
| Crank length | 165mm | 165mm | 170mm | 170mm | 172.5mm | 172.5mm |
| Stem length | 90mm | 90mm | 100mm | 110mm | 110mm | 120mm |
| Handlebar width | 380mm | 380mm | 400mm | 400mm | 400mm | 420mm |
| Handlebar reach | 80mm | 80mm | 80mm | 80mm | 80mm | 80mm |
| Handlebar drop | 125mm | 125mm | 125mm | 125mm | 125mm | 125mm |
| Saddle width | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — |
| Seatpost offset | 20mm | 20mm | 20mm | 20mm | 20mm | 20mm |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Bianchi Specialissima RC carbon High Modulus, only electronic groupsets, fully internal cable routing, headset Acros ICR, direct mount brakes, BB-PressFit 86.5x41 (sizes 47/50/53/55/57/59)
Suspension
Fork
Bianchi Specialissima RC full Carbon High Modulus aero, integrated head, disc, 1.5" head, 12x100mm thru axle
Brakes
Front brake
Campagnolo Super Record, hydraulic disc brake
Rear brake
Campagnolo Super Record, hydraulic disc brake
Front rotor
Campagnolo 03 AFS 160mm
Rear rotor
Campagnolo 03 AFS 160mm
Drivetrain
Shift levers
Campagnolo Super Record WRL
Rear derailleur
Campagnolo Super Record WRL 13sp
Front derailleur
Campagnolo Super Record WRL
Cassette
Campagnolo Super Record, 11-36T
Chain
Campagnolo Super Record
Crankset
Campagnolo Super Record Carbon, 52/36T, powermeter; crank length: 165mm (47-50cm), 170mm (53-55cm), 172.5mm (57-59cm)
Bottom bracket
Campagnolo Quick Tech, Press-Fit 86.5x41
Cockpit
Stem
Bianchi Reparto Corse integrated handlebar (carbon) for Acros Integrated Cable Routing headset; drop 125mm, reach 80mm; size: 90/380mm (47-50cm), 100/400mm (53cm), 110/400mm (55-57cm), 120/420mm (59cm)
Handlebars
Included in the stem (integrated bar/stem)
Grips
Bianchi Arrow premium bar tape, 2.5mm thickness, full black
Saddle
Selle Italia Flite Boost Superflow Carbon
Seatpost
Bianchi Specialissima full carbon, aero shape, 20mm offset; length: 280mm (47cm), 300mm (50-53cm), 350mm (55-59cm)
Wheels & Tires
Front wheel
Campagnolo Bora Ultra WTO, 45mm profile height
Rear wheel
Campagnolo Bora Ultra WTO, 45mm profile height
Front tire
Vittoria Corsa Pro 28-622, TLR, G2.0, 320 TPI, Para/Black
Rear tire
Vittoria Corsa Pro 28-622, TLR, G2.0, 320 TPI, Para/Black
