Bianchi
Impulso Comp GRX 610 Disc 2x12sp (YTB86)
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Spec geometry
| Geometry | LG | MD | SM | XL | XS |
|---|---|---|---|---|---|
| Crank length | 172.5mm | 172.5mm | 170mm | 175mm | 170mm |
| Stem length | 110mm | 100mm | 90mm | 120mm | 80mm |
| Handlebar width | 420mm | 420mm | 400mm | 440mm | 400mm |
| Handlebar reach | 70mm | 70mm | 70mm | 70mm | 70mm |
| Handlebar drop | 130mm | 130mm | 130mm | 130mm | 130mm |
| Saddle width | 149mm | 149mm | 149mm | 149mm | 149mm |
| Dropper post travel | — | — | — | — | — |
| Seatpost offset | 20mm | 20mm | 20mm | 20mm | 20mm |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Bianchi Impulso frame — Disc Brake Specification: Flat Mount 140/160; Bottom Bracket Standard: PressFit 86.5 x Ø41; Rear Axle: thru12; OLD: 142 mm; Front Derailleur: Brazed-on Type; Rear Derailleur: SRAM UDH; Max Chainring Compatibility: 46T-52T
Suspension
Fork
Bianchi Impulso Integrated Fork — Disc Brake Specification: Flat Mount 140/160; Front Axle: thru12; OLD: 100 mm; Tire Clearance: ETRTO 622-42mm; Steerer Tube Diameter: 1 1/8"; Material: Carbon Fiber Composite
Brakes
Front brake
Shimano Hydraulic Brake, BR-RX400
Rear brake
Shimano Hydraulic Brake, BR-RX400
Front rotor
Shimano SM-RT70 IceTech, Centerlock, 160 mm
Rear rotor
Shimano SM-RT70 IceTech, Centerlock, 160 mm
Drivetrain
Shift levers
Shimano GRX 610 ST-RX610
Rear derailleur
Shimano GRX 820 RD-RX820 (max cassette sprocket 36T)
Front derailleur
Shimano GRX 820 FD-RX820
Cassette
Shimano CS-HG710, 12-speed, 11-36T (HG11 driver body interface)
Chain
Shimano CN-M7100
Crankset
Shimano GRX 610 FC-RX610, 46-30T — Crank Length: 170mm (XS 47 / SM 51), 172.5mm (MD 55 / LG 58), 175mm (XL 61)
Bottom bracket
Shimano SM-BB72-41B, press fit
Cockpit
Stem
Velomann AICR Alloy, -2° rise — Steerer: 1-1/8" (28.6mm); Bar clamp: 1-1/4" (31.8mm); Lengths: 80mm (XS 47), 90mm (SM 51), 100mm (MD 55), 110mm (LG 58), 120mm (XL 61)
Handlebars
Velomann Gravel ICR Alloy — Flare: 16°; Drop: 130mm; Reach: 70mm; Clamp: 1-1/4" (31.8mm); Widths: 400 (XS 47 / SM 51), 420 (MD 55 / LG 58), 440 (XL 61)
Grips
La Spirale Ribbon cork
Saddle
Velomann MITORA 149 H1 — cover: soft touch; padding: foam; shell: nylon carbon; open shell; AISI rails; length: 250mm; width: 149mm; weight: 230g ±2
Seatpost
Bianchi Custom D-Shape, 20mm offset — Lengths: 300mm (XS 47), 350mm (SM 51 / MD 55), 380mm (LG 58 / XL 61); Material: Epoxy HM-HS Carbon Fiber Composite
Wheels & Tires
Front wheel
Fulcrum RapidRed 900, 2-Way Fit Ready (clincher & tubeless ready) — 700C; Aluminum alloy; Rim height: 24 mm; Inner width: 22 mm
Rear wheel
Fulcrum RapidRed 900, 2-Way Fit Ready (clincher & tubeless ready) — 700C; Aluminum alloy; Rim height: 24 mm; Inner width: 22 mm
Front tire
Pirelli Cinturato GRAVEL H Classic, 40-622, tan sidewall
Rear tire
Pirelli Cinturato GRAVEL H Classic, 40-622, tan sidewall
