Argon 18
Krypton SRAM Rival AXS
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL | XS | XXS |
|---|---|---|---|---|---|---|
| Stack | 605mm | 584mm | 563mm | 628mm | 543mm | 523mm |
| Reach | 395mm | 386mm | 377mm | 406mm | 367mm | 357mm |
| Headtube length | 186mm | 164mm | 142mm | 208mm | 123mm | 106mm |
| Headtube angle | 72.3deg | 72.3deg | 72.3deg | 72.8deg | 71.5deg | 70.6deg |
| BB height | — | — | — | — | — | — |
| BB drop | 78mm | 78mm | 78mm | 78mm | 80mm | 80mm |
| Trail | — | — | — | — | — | — |
| Fork length | 385mm | 385mm | 385mm | 385mm | 385mm | 385mm |
| Fork offset | 46mm | 46mm | 46mm | 46mm | 52mm | 52mm |
| Front center | 605mm | 590mm | 574mm | 618mm | 569mm | 560mm |
| Chainstay length | 415mm | 415mm | 415mm | 415mm | 415mm | 415mm |
| Wheelbase | 1020mm | 1005mm | 989mm | 1033mm | 984mm | 975mm |
| Top tube | 580mm | 558mm | 537mm | 604mm | 516mm | 496mm |
| Standover height | 801mm | 770mm | 738mm | 832mm | 704mm | 675mm |
| Seat tube length | 555mm | 520mm | 485mm | 590mm | 450mm | 420mm |
| Seat tube angle | 73.1deg | 73.7deg | 74.3deg | 72.5deg | 74.9deg | 75.5deg |
Spec geometry
| Geometry | L | M | S | XL | XS | XXS |
|---|---|---|---|---|---|---|
| Crank length | 172.5mm | 172.5mm | 170mm | 175mm | 170mm | 165mm |
| Stem length | 110mm | 100mm | 90mm | 110mm | 80mm | 70mm |
| Handlebar width | 400mm | 400mm | 380mm | 420mm | 380mm | 380mm |
| Handlebar reach | — | — | — | — | — | — |
| Handlebar drop | — | — | — | — | — | — |
| Saddle width | — | — | — | — | — | — |
| Dropper post travel | — | — | — | — | — | — |
| Seatpost offset | — | — | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
Argon 18 Krypton frame
Suspension
Fork
Argon 18 Krypton fork
Brakes
Front brake
SRAM Rival eTap AXS hydraulic disc
Rear brake
SRAM Rival eTap AXS hydraulic disc
Front rotor
SRAM Paceline Centerlock 160mm
Rear rotor
SRAM Paceline Centerlock 140mm
Drivetrain
Shift levers
SRAM Rival eTap AXS
Rear derailleur
SRAM Rival AXS
Front derailleur
SRAM Rival AXS
Cassette
SRAM Rival AXS Wide XG-1250, 12-speed, 10-36T
Chain
SRAM Rival 12-speed
Crankset
SRAM Rival DUB 46/33 (crank length by size: XXS 165mm; XS/S 170mm; M/L 172.5mm; XL 175mm)
Bottom bracket
TOKEN DUB T47
Cockpit
Stem
FSA SMR (stem length by size: XXS 70mm; XS 80mm; S 90mm; M 100mm; L/XL 110mm)
Handlebars
FSA Energy SCR Compact (bar width by size: XXS/XS/S 38cm c/c; M/L 40cm c/c; XL 42cm c/c)
Saddle
Repente Quasar S 2.0
Seatpost
Argon 18 TDS-C
Wheels & Tires
Front wheel
ATTEN L42 wheelset
Rear wheel
ATTEN L42 wheelset
Front tire
Vittoria Corsa N.EXT 32-622 TLR, black G2.0
Rear tire
Vittoria Corsa N.EXT 32-622 TLR, black G2.0
