3T
RaceMax 2 Italia Super Record PM 2x13 Discus 45|40
Gallery
Images
product
Geometry
Geometry
>
Geometry
Geometry
Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 589mm | 569mm | 547mm | 609mm |
| Reach | 385mm | 377mm | 367mm | 393mm |
| Headtube length | 173mm | 152mm | 138mm | 197mm |
| Headtube angle | 71.5deg | 71.5deg | 70.5deg | 71.5deg |
| BB height | — | — | — | — |
| BB drop | 79mm | 79mm | 79mm | 76mm |
| Trail | — | — | — | — |
| Fork length | 383mm | 383mm | 383mm | 383mm |
| Fork offset | — | — | — | — |
| Front center | 622mm | 607mm | 609mm | 636mm |
| Chainstay length | 420mm | 420mm | 420mm | 420mm |
| Wheelbase | 1029mm | 1015mm | 1017mm | 1045mm |
| Top tube | 552mm | 538mm | 522mm | 566mm |
| Standover height | — | — | — | — |
| Seat tube length | 510mm | 491mm | 463mm | 537mm |
| Seat tube angle | 74deg | 74deg | 74deg | 74deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | 172.5mm | 170mm | 170mm | 172.5mm |
| Stem length | 100mm | 90mm | 80mm | 110mm |
| Handlebar width | 420mm | 400mm | 400mm | 420mm |
| Handlebar reach | — | — | — | — |
| Handlebar drop | — | — | — | — |
| Saddle width | 140mm | 140mm | 140mm | 140mm |
| Dropper post travel | — | — | — | — |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
3T RaceMax2 ITALIA Integrale (UDH), integrated storage with Fidlock closure system
Suspension
Fork
3T Fango RaceMax2 Integrale w/ compact crown
Brakes
Front brake
Campagnolo Super Record hydraulic disc
Rear brake
Campagnolo Super Record hydraulic disc
Front rotor
160mm
Rear rotor
160mm
Drivetrain
Shift levers
Campagnolo Super Record WRL 2x13 shift/brake levers
Rear derailleur
Campagnolo Super Record WRL 13-speed, Direct Mount
Front derailleur
Campagnolo Super Record WRL 13-speed
Cassette
Campagnolo Super Record 13-speed, 10-33T
Chain
Campagnolo Super Record 13-speed
Crankset
Campagnolo Super Record Power Meter 45/29 (S&M: 170mm; L&XL: 172.5mm)
Bottom bracket
Campagnolo (not specified)
Cockpit
Stem
3T More (K-Edge GPS mount included) (S: 80mm; M: 90mm; L: 100mm; XL: 110mm)
Handlebars
3T Aeroghiaia Integrale LTD (S&M: 40cm; L&XL: 42cm)
Saddle
Fizik Vento Argo R1 Light 140mm
Seatpost
3T RaceMax/RaceMax2 ITALIA seatpost for Ritchey clamp with integrated light system
Wheels & Tires
Front wheel
3T Discus 45|40 LTD
Rear wheel
3T Discus 45|40 LTD
Front tire
Schwalbe G-One RS 700x45
Rear tire
Schwalbe G-One RS 700x45
