Frame geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Stack | 575mm | 546mm | 517mm | 604mm |
| Reach | 390mm | 378mm | 366mm | 402mm |
| Headtube length | 150mm | 125mm | 101mm | 180mm |
| Headtube angle | 72.5deg | 71.1deg | 69.5deg | 72.5deg |
| BB height | — | — | — | — |
| BB drop | 70mm | 70mm | 70mm | 70mm |
| Trail | — | — | — | — |
| Fork length | 395mm | 395mm | 395mm | 395mm |
| Fork offset | 50mm | 50mm | 50mm | 50mm |
| Front center | 606mm | 598mm | 591mm | 627mm |
| Chainstay length | 415mm | 415mm | 415mm | 415mm |
| Wheelbase | 1011mm | 1003mm | 996mm | 1032mm |
| Top tube | 571mm | 550mm | 529mm | 592mm |
| Standover height | — | — | — | — |
| Seat tube length | 518mm | 490mm | 463mm | 545mm |
| Seat tube angle | 72.5deg | 72.5deg | 72.5deg | 72.5deg |
Spec geometry
| Geometry | L | M | S | XL |
|---|---|---|---|---|
| Crank length | 172.5mm | 170mm | 170mm | 172.5mm |
| Stem length | 100mm | 90mm | 80mm | 110mm |
| Handlebar width | 420mm | 400mm | 400mm | 420mm |
| Handlebar reach | 77mm | 77mm | 77mm | 77mm |
| Handlebar drop | 123mm | 123mm | 123mm | 123mm |
| Saddle width | 140mm | 140mm | 140mm | 140mm |
| Dropper post travel | — | — | — | — |
| Seatpost offset | — | — | — | — |
Specs
Full specs
>
Specs
Full specs
Frame
Frame
3T Primo2 UDH — unidirectional pre-preg carbon, high-modulus/high-strength performance blend layup
Suspension
Fork
3T Fango Primo2
Brakes
Front brake
Shimano BR-RX400 hydraulic disc
Rear brake
Shimano BR-RX400 hydraulic disc
Front rotor
Shimano SM-RT64 160mm
Rear rotor
Shimano SM-RT64 160mm
Drivetrain
Shift levers
Shimano GRX ST-RX610, 12-speed (shift/brake levers)
Rear derailleur
Shimano GRX RD-RX822 GS RD+, 12-speed
Cassette
Shimano Deore CS-M6100-12, 12-speed, 10-51T
Chain
null
Crankset
Shimano FC-RX610-1, 40T, 12-speed (S&M: 170mm; L&XL: 172.5mm)
Bottom bracket
null
Cockpit
Stem
3T APTO with semi-integrale spacer kit (S: 80mm; M: 90mm; L: 100mm; XL: 110mm)
Handlebars
3T Superergo Pro (S&M: 40cm; L&XL: 42cm)
Grips
3T Prendo Tough (bar tape)
Saddle
Fizik Vento Argo X5, 140mm
Seatpost
3T Primo setpost for Ritchey clamp
Wheels & Tires
Front wheel
Fulcrum Rapid Red 900 700c or Fulcrum Racing 600 700c
Rear wheel
Fulcrum Rapid Red 900 700c or Fulcrum Racing 600 700c
Front tire
Pirelli Cinturato Adventure 700×45 or Vittoria Terreno T30 Sport 700×40
Rear tire
Pirelli Cinturato Adventure 700×45 or Vittoria Terreno T30 Sport 700×40
